Description
An extensive range of scopes to suit all calibres and disciplines.
All Vantage riflescopes feature our H2 optics in a variety of configurations.
IR models feature precision glass etched reticles with multi-stage illumination in both red and green.
- Exposed Locking Turrets
- 30mm Mono-Tube Chassis
- Wide Angle
- Side Focus
- Illumination
- 11 Layer Fully Multi-Coated Lenses
- High Torque Zoom Ring
- Fast Focus Eyebell
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke No-Fault Lifetime Warranty.
10x Half Mil Dot Reticle
Accurate mil spacing on 10x. Features dots and ties at half mil spacing, ensuring that there is always an aim point available. Glass etched fully floating reticle.
One of the additional benefits of the 10x Half Mil Dot is the mil spacing and 0.2 mil spacing segments of the hollow bars which can be used to accurately range find targets.
Length:
347mm
13.7"
Weight:
740g
26.1oz
Eye relief:
90mm
3.5"
Focus/Parallax - Side Focus
9m - ∞
10yds - ∞
Field of View:
9.6 - 2.6m @100m
28.8 - 7.8ft @100yds
Exit Pupil:
12.5-3.1mm
0.49-0.12"
Chassis
30mm Mono-tube
Optical System
4-16×
Objective
50mm
Illumination
Red / Green
Reticle
Half Mil Dot
Elevation Increment
1⁄10 MRAD
Elevation Adjustment Range:
28 MRAD
Windage Increment
1⁄10 MRAD
Windage Adjustment Range
28 MRAD
Material
Aluminium
Ocular Type
Fast Focus
Lens Coating
Fully Multi-Coated - 11 Layers
Power Selector Style
Knurled Posi-Grip
Focal Plane
Second Focal Plane (SFP)
Turret Caps
No
Turret Type
Exposed, Locking
-
SUPPLIED WITH
Box
Instruction Manual
Riflescope Alignment Booklet
Lens Covers
Lens Cloth
